Orchestration

Orchestration engine in AgenticX.

Orchestration

Overview

AgenticX provides two complementary orchestration approaches:

Graph-based Workflows — explicit DAG with nodes and edges, full control
Flow Decorators — lightweight pipeline definition with Python decorators

Graph-based Workflow

python

1from agenticx.flow import Workflow, Node, Edge
2
3workflow = Workflow(id="research-pipeline")
4
5# Define nodes (each node is an agent task)
6fetch = Node(id="fetch", agent=fetch_agent, task=fetch_task)
7analyze = Node(id="analyze", agent=analyze_agent, task=analyze_task)
8report = Node(id="report", agent=report_agent, task=report_task)
9
10# Define edges (data flow)
11workflow.add_edge(Edge(source="fetch", target="analyze"))
12workflow.add_edge(Edge(source="analyze", target="report"))
13
14result = workflow.run()

Conditional Routing

python

1from agenticx.flow import ConditionalEdge
2
3def route_based_on_result(output):
4    if output.confidence > 0.8:
5        return "publish"
6    else:
7        return "review"
8
9workflow.add_edge(
10    ConditionalEdge(
11        source="analyze",
12        condition=route_based_on_result,
13        targets={"publish": publish_node, "review": review_node}
14    )
15)

Parallel Execution

python

1from agenticx.flow import ParallelNode
2
3# Run multiple agents concurrently
4parallel = ParallelNode(
5    id="parallel-research",
6    nodes=[fetch_news, fetch_papers, fetch_code],
7    merge_strategy="concat"
8)
9workflow.add_node(parallel)

Flow Decorators

For simpler pipelines, use the @flow decorator system:

python

1from agenticx.flow import flow, step
2
3@flow
4class ResearchPipeline:
5
6    @step
7    def fetch_data(self, query: str) -> str:
8        return self.fetch_agent.run(query)
9
10    @step
11    def analyze(self, data: str) -> dict:
12        return self.analyze_agent.run(data)
13
14    @step
15    def generate_report(self, analysis: dict) -> str:
16        return self.report_agent.run(analysis)
17
18pipeline = ResearchPipeline()
19result = pipeline.run(query="Latest AI research")

Execution Plans

For complex multi-step tasks, use execution plans:

python

1from agenticx.planner import ExecutionPlan, PlanStep
2
3plan = ExecutionPlan(
4    steps=[
5        PlanStep(id="1", description="Gather requirements", agent=analyst),
6        PlanStep(id="2", description="Design architecture", agent=architect, depends_on=["1"]),
7        PlanStep(id="3", description="Implement features", agent=developer, depends_on=["2"]),
8        PlanStep(id="4", description="Write tests", agent=tester, depends_on=["3"]),
9    ]
10)
11
12results = plan.execute()
